Rotary Table 3″ inch – 75mm Horizontal & Vertical Model- Milling Machine 4 slots

3,200.00

Rotary Table 3″ inch – 75mm Horizontal & Vertical Model- Milling Machine 4 slots

ter 80 mm (3″Inches ) . Table is graduated 360 Degrees.
Worm Gear Ratio -1:36, which means that the 1 handle rotation shall turn the table by 10 Degrees.
Center Height in vertical position without chuck: 2-5/8″ (66 mm approx)
Hand wheel is graduated in divisions of 10 min & can be set to zero.
Can be mounted both in Horizontal & vertical position.

Rotary Table 3 Inch – 75mm Horizontal & Vertical Model.
Base Dimensions: 4. 1/8″ x 3. 1/4″ 4 T-Slots: 5/16″ – Vertical Height – 1-5/8 Inch
Table Scale is Calibrated in 5 degree increment. Can be used both in horizontal & vertical position.
Gear Ratio – 36:1, which basically means that the 1 rotation of the handle shall rotate the table by 10 degrees.
Manufacturer BREEZE TOOLS
Part Number BTIRTBTB3
Item Weight ‎4.56 pounds
Package Dimensions ‎7.91 x 5.98 x 3.62 inches
Country of Origin ‎India
Is Discontinued By Manufacturer ‎No
Size ‎3”
Color ‎SILVER
Style ‎3″ inch – 75mm
Material ‎CASTE IRON & TOOL STEEL

Rotary Table 3″ inch – 75mm Horizontal & Vertical Model- Milling Machine 4 slots

ter 80 mm (3″Inches ) . Table is graduated 360 Degrees.
Worm Gear Ratio -1:36, which means that the 1 handle rotation shall turn the table by 10 Degrees.
Center Height in vertical position without chuck: 2-5/8″ (66 mm approx)
Hand wheel is graduated in divisions of 10 min & can be set to zero.
Can be mounted both in Horizontal & vertical position.

Rotary Table 3 Inch – 75mm Horizontal & Vertical Model.
Base Dimensions: 4. 1/8″ x 3. 1/4″ 4 T-Slots: 5/16″ – Vertical Height – 1-5/8 Inch
Table Scale is Calibrated in 5 degree increment. Can be used both in horizontal & vertical position.
Gear Ratio – 36:1, which basically means that the 1 rotation of the handle shall rotate the table by 10 degrees.
Manufacturer BREEZE TOOLS
Part Number BTIRTBTB3
Item Weight ‎4.56 pounds
Package Dimensions ‎7.91 x 5.98 x 3.62 inches
Country of Origin ‎India
Is Discontinued By Manufacturer ‎No
Size ‎3”
Color ‎SILVER
Style ‎3″ inch – 75mm
Material ‎CASTE IRON & TOOL STEEL

Best Offer:
SINGLE QTY 5% OFF
DOUBLE QTY 7.5% OFF
TEN OR MORE THAN 10% OFF
SKU: BTIRTBTB3 Category: Tag:

Description



DESCRIPTION:-

Table diameter 80 mm (3″) Table is graduated 360 Degrees. Worm Gear Ratio -1:36, which means that the 1 handle rotation shall turn the table by 10 Degrees. Center Height in vertical position without chuck: 2-5/8″ (66 mm approx) Hand wheel is graduated in divisions of 10 min & can be set to zero. Can be mounted both in Horizontal & vertical position

Additional information

Weight 2.100 kg
